cat6 sftp lan cable 305m 0.57cca network cable

FOB Reference Price:Get Latest Price
$0.02 - $0.08 / Meter | 3000 Meter/Meters (Min. Order)
Samples:
Shipping:
Support Sea freight
Lead Time:
Quantity(Meters) 1 - 1 2 - 100 101 - 500 >500
Est. Time(days) 7 10 15 Negotiable
Customization:
Customized logo (Min. Order: 30000 Meters)
Customized packaging (Min. Order: 30000 Meters)

More

Graphic customization (Min. Order: 30000 Meters) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Kunlian
Model Number:
cat6 stp network cable
Number of Conductors:
8
Product name:
cat6 sftp lan cable 305m 0.57cca network cable
Conductor:
Solid Bare Copper
Insulation:
HD-PE
inner shileded:
Al-mylar
outer shileded:
CCA
jacket:
PVC
Pairs:
4
Color:
blue,as your request
Shield:
utp/ftp/sftp
Operating temperature:
60--75
Supply Ability
Supply Ability:
500000 Meter/Meters per Day cat6 sftp lan cable 305m 0.57cca network cable
Packaging & Delivery
Packaging Details
305meters or 1000ft per box Two boxes into a carton
Port
SHENZHEN
Lead Time :
Quantity(Meters) 1 - 1 2 - 100 101 - 500 >500
Est. Time(days) 7 10 15 To be negotiated

cat6 sftp lan cable 305m 0.57cca network cable

Product Description



sftp Cat6 network cable
Brand  nameKunlian
Conductor23AWG/24AWG/26AWG Solid Bare Copper
InsulationHD-PE
 shileded

Inner Shielded:AL-Mylar 100% coverage

outer Shielded:CCA

fillerPE Cross
JacketPVC
Inner  cable  color  codeOrange/white-Orange ,Green/White-Green,Blue/White-Blue,Brown/White-Brown
Jacket colorblue, as your request
PackageBox,carton ,according to your request
cable  length  in  each  box100-305m
shippingBy Sea  ,     By Express      , can be negotiated
rated   temperature60℃ or  75℃
Detailed Images





Comparison of cat5 and cat6

About Cat5 system
100Base-T is the standard applied by the Cat5e system during the Gigabit Ethernet transaction, which could run
properly on the Cat5 Twist-Pair that meets the standard of ANSI/TIA/EIA-568A (1995).1000Base-T would finish the data transaction by applying to 4 pairs of Cat5 Twist-Pair and each of them is responsible for a 250Mbps data flow. However, as the designed bandwidth is only 100MHz for the Cat5 & Cat5e Twist-Pair, it must satisfy some special requirements to achieve the two-way transmission within the 1000Mbps network.


About Cat6 system
1000BASE-Tx is the working style for Cat6 system. Similarly, 1000Base-Tx works on the basis of 4 pairs of
Twist-Pair; but two of them are for sending while the other two are for receiving(similar to the 100Base-TX, who sends and receives data respectively by two Twist-Pair). Each pair of cables doesn't conduct a two-way transmission themselves; therefore the crosstalk between cables decreases greatly, along with a relatively simple coding way. Such kind of technology has a lower requirement on the network interface. It doesn't require quite a complicated circuit design thus the cost on network interface is decreased. Whereas, along with the efficiency decrease of the used cables (two for sending and two for receiving), the bandwidth is required to be over 100mhz so as to achieve a 1000mbps transmission speed;i.e. such kind of network is not supported in the Cat5&Cat5e system but will only be supported by the Cat6 system.




cat5
cat6
Maximum length
100m
100m
Bandwidth
100Mhz
250Mhz
Disturbance resistant
Normal
Good
Suitable for
100BASE-TX (Fast Ethernet)
1000BASE-T (Gigabit Ethernet)
Diamater
5.2mm
5.8mm
Theoretical download
12.8 M/s
128 M/s
Packaging & Shipping



Package Details:




 Shipping:

             by Sea, by Express,can be negotiated



Company Information



Jiexi KunLian cable factory is located in Jiexi, Jieyang city,Guangdong,China.

We have high productivity and strict quality assurance.There are some skilled workers and complete equipments in the factory.

Certifications



FAQ



FAQ

Q1:What kind of cable do you produce?

We're direct & professional manufacturer that producing communication cable, such as cat5,cat5e,cat6,cat7; patch cord; coaxial cable, ; power cable, etc.

Q2:The MOQ order?

Our MOQ is 30000 Meters per item. Free sample can be supply for your quality evaluation.

Q3:Payment term?

Normally T/T,30% deposit before production, the balance paid before delivery. Other payments accept through negotiation.

Q4:Time delivery?

1*20'GP: Within 10 days after receive deposit.

1*40'GP: Within 12 days after receive deposit.

1*40'HQ: Within 15 days after receive deposit.

Welcome to order our cable which is in stock, it is only 2 days for delivery time.

Q5:What about the after-sales service?

Our cable will provide free change for new if there is any quality problem in your order.

Q6:Why choose us?

"7 Professional "as below:

Professional manufacturer: Professional in making various cables of 9 years experience.

Professional products: Using high quality raw material.

Professional price: Factory price with high quality.

Professional service: Fast response within 24hours for any requirements.

Professional requires: Offer OEM, ODM services.

Professional delivery: Strict production plan and delivery date.

Professional Customization: Welcome more customers requirements and design.

Q7,Any other question,plz contact us

Contact us





Please don't hesitate to contact us ,we will give you the best answer .

Thank you for your time!
